H PILES
(HP)

H-Pile

H pile is versatile, reusable and recyclable


H pile offers project planners many options due to its unique structure and chemical makeup. For instance, it is extremely beneficial when used in seismic areas due to the ductility of steel and the large surface area making it ideal for friction piling.



H pile is generally used in deep foundations where there are rough soil conditions. Project planners can use the product to carry out test piles and then once extracted, the piles are reusable or recyclable.


H pile is commonly used in:

  • Braced excavations
  • Friction piling
  • Test piles
  • False work
  • Building construction
  • Bridges
  • Soldier beams

Processing Capabilities

METALS PROCESSING


SPEC A-36 / 44W
A572-50 / A992
H PILES (HP)

DESCRIPTION

A36 is a structural quality carbon steel for use in welded, bolted or riveted construction of bridges and buildings, and for general structural purposes.
COMMON STOCK LENGTH (feet)
40 / 50 / 60

VARSTEEL REFERENCE GUIDE

ASTM Imp. CDN Metric Depth In. Width In. Thickness (mean) In. Web Thickness In. Section Modulus In.3
HP8 x 36 HP200 x 54 8.02 8.16 0.445 0.445 29.8
HP10 x 42 HP250 x 62 9.70 10.08 0.420 0.415 43.4
x 57 x 85 9.99 10.22 0.565 0.565 58.8
HP12 x 53 HP310 x 79 11.78 12.04 0.435 0.435 66.8
x 63 x 94 11.94 12.13 0.515 0.515 79.1
x 74 x 110 12.13 12.22 0.610 0.605 93.8
x 84 x 125 12.28 12.28 0.685 0.685 106
x 89 x 132 12.35 12.33 0.720 0.720 111
x 102 x 152 12.55 12.62 0.820 0.820 129
x 117 x 174 12.77 12.87 0.930 0.930 149
HP14 x 73 HP360 x 108 13.61 14.58 0.505 0.505 107
x 89 x 132 13.83 14.70 0.615 0.615 131
x 102 x 152 14.01 14.78 0.705 0.705 150
x 117 x 174 14.21 14.88 0.805 0.805 172
HP16 x 88 HP410 x 131 15.31 15.67 0.54 0.54 -
x 101 x 151 15.51 15.75 0.63 0.63 -
x 121 x 181 15.75 15.87 0.75 0.75 -
x 141 x 211 15.98 15.98 0.87 0.87 -
x 162 x 242 16.26 16.14 1.00 1.00 -
x 183 x 272 16.50 16.26 1.13 1.13 -
HP18 x 135 HP460 x 202 17.52 17.76 0.75 0.75 -
x 157 234 17.76 17.87 0.87 0.87 -
x 181 269 17.99 17.99 1.00 1.00 -
x 204 304 18.27 18.11 1.13 1.13 -
